sky130.pcells.contact_array#

sky130.pcells.contact_array(width=0.29, height=0.29, contact_layer=(66, 44), contact_size=(0.17, 0.17), contact_spacing=(0.17, 0.17), enclosure=(0.06, 0.06))[source]#

Return a centered array of contacts/vias within the area of width x height.

Uses floor rounding to match Magic’s contact placement behavior.

Parameters:

  • width (float) – width of the enclosing area.

  • height (float) – height of the enclosing area.

  • contact_layer (tuple[int, int] | str | int | LayerEnum) – layer for the contact rectangles.

  • contact_size (tuple[float, float]) – (x, y) size of each contact.

  • contact_spacing (tuple[float, float]) – (x, y) spacing between contacts.

  • enclosure (tuple[float, float]) – (x, y) minimum enclosure of contacts within the area.

Return type:

Component

import sky130

c = sky130.pcells.contact_array()
c.plot()

(Source code, png, hires.png, pdf)

../_images/sky130-pcells-contact_array-1.png
